MVVS 116 NP Boxer

All MVVS run a full crank( like MX or GKart), to minimise vibrations, and be gentle to all onboard systems, unlike most RC engines.

MVVS 116 Boxer is HI-TECH between petrol engines twins. It is based on MVVS58.
Intake is controlled by reed valve. Exhaust systems are orientated under engine. Crankshaft fitted on on two ball bearing and on one needle bearing and connecting rod has both holes equipped with needle bearings INA. Pistons are made from aluminum composition with high content of silicium. Pistons are coated by special sliding coat, which force running-in the engine and extend engine service life. Cylinders from aluminum composition have working area coated by NIKASIL. Also this engine holds performance primacy in 120´s petrol engines class. Engine is suitable for all kind of models and also has good exploitation for racing acrobatic flight.

Item number    3010 - including carburetor, ignition, spark plugs+key and oil 250ml
Displacement    116 cm3
Bore / Stroke    42 / 42 mm
Weight Without Ignition    3100 g
Ignition    ICU-B electronic, microprocessor, automatic choke control
Ignition Weight    210 g
Carburetor    Walbro
Max Power Output    11 PS/5900 RPM
Propeller
RPM
Exhaust
 30"x10" Mejzlík
 6200
3511/3611
